Farbfernsehchassis FM 100
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1975/1976
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 290407
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Prospekt 1975/76
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Material
- Various materials
- from Radiomuseum.org
- Model: Farbfernsehchassis FM 100 - Blaupunkt Ideal, Berlin,
- Shape
- Chassis only or for «building in»
- Notes
-
Funktionsmodulchassis FM100 der Serien 7.665.xxx und 7.666.xxx
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Richard Winter. See "Data change" for further contributors.
