Frankfurt 7.632.640 ab 5500001
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1972
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 80538
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Transistors
- 14
- Semiconductors
- AF106 BF255 BF540 BF540 BF540 BF254 BF450 BF255 BF451 BC238 BC238 BC328 AD156 AD157 BA111 AA119 1N4148 ZPD9,1
- Main principle
- Superheterodyne (common); ZF/IF 460 or 452/10700 kHz
- Tuned circuits
- 8 AM circuit(s) 13 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 5 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Frankfurt 7.632.640 ab 5500001 - Blaupunkt Ideal, Berlin,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 178 x 43 x 135 mm / 7 x 1.7 x 5.3 inch
- Notes
- DIN -Buchse für EXT NF-Quellen.
- Net weight (2.2 lb = 1 kg)
- 1.2 kg / 2 lb 10.3 oz (2.643 lb)
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Bernd Pötzsch. See "Data change" for further contributors.
- Other Models
-
Here you find 3591 models, 3279 with images and 2330 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Blaupunkt (Ideal), Berlin, später Hildesheim
Collections
The model Frankfurt is part of the collections of the following members.
Forum contributions about this model: Blaupunkt Ideal,: Frankfurt 7.632.640 ab 5500001
Threads: 1 | Posts: 5
Autoradio Blaupunkt voll transistorisiert, mit 5 Drucktasten KMLUU, UKW-Bereich bis 104 MHz,Skala:Frequenz nach rechts steigend von links 89MHz auf 104 MHz.Wer kann dazu Angaben machen? Viele Grüße und Danke im voraus Klemens Rhode.
Attachments
- Modell (70 KB)
Klemens Rhode, 18.May.08
