Frankfurt US 7.638.650 ab Z 620001

Blaupunkt (Ideal), Berlin, später Hildesheim

Data
Forum
Pictures
Collections

  • Year
  • 1968/1969
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 153300
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 11
  • Main principle
  • Superheterodyne (common); ZF/IF 460 or 452/10700 kHz; Export model
  • Tuned circuits
  • 8 AM circuit(s)     13 FM circuit(s)
  • Wave bands
  • Broadcast, Short Wave plus FM or UHF.
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 6 / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 5 W (unknown quality)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Frankfurt US 7.638.650 ab Z 620001 - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 178 x 50 x 147 mm / 7 x 2 x 5.8 inch
  • Notes

  • Frankfurt US 7 638 650 von Blaupunkt ist ein Überseemodell (Export-Ausführung)
    mit Senderschnellwahl durch 5 Stations-Drucktasten: 2 x FM, 2 x SW, 2 x AM.

    Empfangsbereiche:
    AM (MW), 515 - 1640 kHz;
    SW (KW), 49 m;
    FM (UKW), 87 - 108 MHz.

    Dioden teilweise mehrfach vorhanden.

  • Mentioned in
  • Original Blaupunkt Service Unterlagen
  • Literature/Schematics (1)
  • -- Original-techn. papers.
  • Author
  • Model page created by Josef Pilz. See "Data change" for further contributors.
