Hannover DAB 106A

Blaupunkt (Ideal), Berlin, später Hildesheim

Data
Forum
Pictures
Collections

  • Year
  • 1996 ?
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 248080
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 10700 kHz
  • Wave bands
  • DAB and FM, perhaps with Streaming [DABFM]
  • Details
  • Other Combination - see Notes
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 20 W (25 W max.)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Hannover DAB 106A - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Notes

  • Blaupunkt Hannover DAB 106A,

    DAB-Empfangsteil in separater Box. Cassettenwiedergabe.
    Zusätzliche Anschlussmöglichkeit für CD Wechsler CDC-A05 und CDC-A08

  • Price in first year of sale
  • 599.00 DM
  • Mentioned in
  • Bedienungsanleitung
  • Author
  • Model page created by Torsten Becker. See "Data change" for further contributors.
