Ingolstadt Stereo (D) 7.638.425.000 VW 171 035 160
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1978 ?
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 265445
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Material
- Metal case
- from Radiomuseum.org
- Model: Ingolstadt Stereo 7.638.425.000 VW 171 035 160 - Blaupunkt Ideal, Berlin,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 180 x 45 x 170 mm / 7.1 x 1.8 x 6.7 inch
- Notes
-
Senderspeicher: 2 x MW, 4 x UKW (6 Drucktasten, davon 1x UKW-VF).
ARI-Verkehrsfunk-Decoder mit Sender- und Durchsagekennung.
LED-Anzeige für Stereosendung (grün), VF-Sender (gelb), Verkehrsfunk-Durchsage (rot).Vertrieb von VW/Audi mit der Teile-Nr. 171 035 160.
- Net weight (2.2 lb = 1 kg)
- 1.2 kg / 2 lb 10.3 oz (2.643 lb)
- Author
- Model page created by Jürgen Küting. See "Data change" for further contributors.
