Köln Stereo-Super-Arimat 7.636.743.012 ab 1465001

• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1977/1978

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 125650

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 75

• Semiconductors

• Main principle
• Superheterodyne (common)

• Tuned circuits
• 9 AM circuit(s)     8 FM circuit(s)

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: Köln Stereo-Super-Arimat 7.636.743.012 ab 1465001 - Blaupunkt Ideal, Berlin,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 179 x 43 x 109 mm / 7 x 1.7 x 4.3 inch

• Notes
• ICs: 4, Dickschichtschaltungen: 10, Hybridschaltungen: 1.
  Stereo-NF-Verstärker mit 2 Endstufen je 5 W. Motorischer Suchlauf. Verkehrslotsen-Elektronik in separatem Baustein.

• Source of data
• Handbuch VDRG 1977/1978

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
