Lido 93.350
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1963/1964
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 352199
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common); Export model
- Wave bands
- Broadcast, Short Wave plus FM or UHF.
- Power type and voltage
- Dry Batteries / 3R12: 2 x 4.5 V or 6F22: 1 x 9 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Lido 93.350 - Blaupunkt Ideal, Berlin,
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 238 x 157 x 75 mm / 9.4 x 6.2 x 3 inch
- Notes
-
FM 87 - 108 MHz, SW 4.5 - 12 MHz, AM 510 - 1630 kHz
See also the German domestic model Blaupunkt Lido 93.330 with FM up to 104 MHz and LW instead of SW.
- Author
- Model page created by Kevin Gregson. See "Data change" for further contributors.
