Lille 7.636.626.012
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1977/1978
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 125592
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
- Number of Transistors
- 20
- Main principle
- Superheterodyne (common)
- Tuned circuits
- 6 AM circuit(s) 7 FM circuit(s)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 5 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Lille 7.636.626.012 - Blaupunkt Ideal, Berlin,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 179 x 43 x 106 mm / 7 x 1.7 x 4.2 inch
- Notes
-
ICs: 1; Hybridschaltungen: 2. 5 Stationstasten zur Festsender-Speicherung (5x MW, 5x UKW umschaltbar).
Siehe auch Lille 7.636.626.
- Net weight (2.2 lb = 1 kg)
- 1 kg / 2 lb 3.2 oz (2.203 lb)
- Source of data
- Handbuch VDRG 1977/1978
- Author
- Model page created by Bernd P. Kieck. See "Data change" for further contributors.
