Madrid RCM 105 7 644 776 510

Blaupunkt (Ideal), Berlin, später Hildesheim

Data
Forum
Pictures
Collections

  • Year
  • 1994
  • Category
  • Car Radio, perhaps also + sound player/recorder
  • Radiomuseum.org ID
  • 286563
    • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
    • Brand: Rotstern

 Technical Specifications

  • Number of Transistors
  • 49
  • Main principle
  • PLL, Phase-locked loop
  • Wave bands
  • FM Broadcast Band Only
  • Details
  • Cassette-Recorder or -Player
  • Power type and voltage
  • Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 80 W (undistorted)
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Madrid RCM 105 7 644 776 510 - Blaupunkt Ideal, Berlin,
  • Shape
  • Chassis only or for «building in»
  • Dimensions (WHD)
  • 179 x 50 x 150 mm / 7 x 2 x 5.9 inch
  • Notes
    • Codem IV-UKW-Tuner, RDS/EON, Travelstore,
    • 3 x 6 storage locations in FM,
    • Autoreverse,
    • DMS - Disc Management System,
    • Regler für Höhen/Tiefen/Balance/Fader,
    • 4 x 20W Sinus, Preamp Out, Flex Fader,
    • DSC Direct Software Control,
    • Flashing KeyCard,
    • Telefon Mute

    LF frequency range: FM 35 - 16,000 Hz; Cassette: 30 - 16,000 Hz.
    49 Transistors, 27 ICs, 31 Diodes, 45 LED and 10 Quartz. Semiconductors listed one per type and not all.

  • Net weight (2.2 lb = 1 kg)
  • 1.2 kg / 2 lb 10.3 oz (2.643 lb)
  • Mentioned in
  • -- Original prospect or advert (Blaupunkt Mobile Audio Systems´94/´95)
  • Author
  • Model page created by Roland Müller. See "Data change" for further contributors.
