• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1973/1974

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 116836

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 1

• Valves / Tubes
• A67-150X

• Number of Transistors
• 88

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Wooden case

• from Radiomuseum.org
• Model: Monitor C1 7.664.820 - Blaupunkt Ideal, Berlin,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 650 x 613 x 475 mm / 25.6 x 24.1 x 18.7 inch

• Notes
• 7 ICs. VHF/UHF-Allbereichtuner. Trompetenfuß gegen Mehrpreis.

• Net weight (2.2 lb = 1 kg)
• 41 kg / 90 lb 4.9 oz (90.308 lb)

• Source of data
• Handbuch VDRG 1973/1974

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
