• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1964 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 82403

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 9

• Semiconductors
• AF115 AF115 AF117 AF117 OC75 OC75 OC75 OC74 OC74 OA79 E20C30 E12,5C5

• Main principle
• Superheterodyne (common); ZF/IF 460 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Storage and/or dry batteries / 6 × 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch

• Power out
• 1 W (unknown quality)

• from Radiomuseum.org
• Model: Nixe 93610 [ab U 200001] - Blaupunkt Ideal, Berlin,

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 273 x 198 x 87 mm / 10.7 x 7.8 x 3.4 inch

• Notes

• Betrieb im Auto über Einbauhalterung HV450 93950 gegen Mehrpreis (41,50 DM).

• Net weight (2.2 lb = 1 kg)
• 2.2 kg / 4 lb 13.5 oz (4.846 lb)

• Mentioned in
• -- Original-techn. papers. (Service-Manual, EVB 936-079, Serie U)

• Author
• Model page created by Bernd Pötzsch. See "Data change" for further contributors.
