• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1990

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 154674

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 28

• Semiconductors

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz; none

• Wave bands
• Broadcast (BC) and FM or UHF.

• Details
• Cassette-Recorder or -Player; Radio with other functions

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 2 W (unknown quality)

• Material
• Metal case

• from Radiomuseum.org
• Model: Opel SC 202B / 7 648 855 521 - Blaupunkt Ideal, Berlin,

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 180 x 55 x 170 mm / 7.1 x 2.2 x 6.7 inch

• Notes
• 3 FET, 9 IC, up-Steuerung mit upd 7514, Cassettenspieler mit magn. Auswurf, 7 Segment LCD Display, Verkehrsfunkdecoder, "Senderkralle" autom. Belegung der Stationstasten.

• Net weight (2.2 lb = 1 kg)
• 1.1 kg / 2 lb 6.8 oz (2.423 lb)

• Price in first year of sale
• 610.00 DM

• Author
• Model page created by Thomas Ottstadt. See "Data change" for further contributors.
