Parade de Luxe 2571 Export
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1958/1959
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 130380
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC)
- Loudspeaker
- 2 Loudspeakers
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Parade de Luxe 2571 [Export] - Blaupunkt Ideal, Berlin,
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 540 x 340 x 240 mm / 21.3 x 13.4 x 9.4 inch
- Notes
- Exportgerät, Wellenbereiche LW, MW, 3 x KW.
- Net weight (2.2 lb = 1 kg)
- 9.4 kg / 20 lb 11.3 oz (20.705 lb)
- Price in first year of sale
- 268.00 DM
- Source of data
- -- Original-techn. papers.
- Author
- Model page created by Walter Groer. See "Data change" for further contributors.
