Rundfunk-Einbauchassis 7.628.180
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1969 ?
- Category
- Radio module post 1925 (not a part, not a key)
- Radiomuseum.org ID
- 337344
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
- Number of Transistors
- 37
- Semiconductors
- Main principle
- Superheterodyne (common); ZF/IF 460/10700 kHz
- Tuned circuits
- 7 AM circuit(s) 12 FM circuit(s)
- Wave bands
- Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 127; 220; 240 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 44 W (undistorted)
- Material
- Various materials
- from Radiomuseum.org
- Model: Rundfunk-Einbauchassis 7.628.180 - Blaupunkt Ideal, Berlin,
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 580 x 130 x 230 mm / 22.8 x 5.1 x 9.1 inch
- Notes
-
Das Rundfunk-Chassis 7.628.180 wurde unter anderem im Blaupunkt HiFi-Musikstudio New York eingebaut.
- Author
- Model page created by Florian Henkel. See "Data change" for further contributors.
