Omnibus-Sprechanlage Kassel
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1960–1964
- Category
- Audio Amplifier or -mixer
- Radiomuseum.org ID
- 24086
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Q: Blaupunkt Service
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 1
- Valves / Tubes
- ECF83
- Number of Transistors
- 3
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12; 24 Volt
- Loudspeaker
- - This model requires external speaker(s).
- Power out
- 12 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: Omnibus-Sprechanlage Kassel - Blaupunkt Ideal, Berlin,
- Notes
- Gerät besteht aus Bedienteil und Verstärkerteil.
- Price in first year of sale
- 396.00 DM
- External source of data
- Erb
- Mentioned in
- HdB d.Rdf-& Ferns-GrH 1960/61 (bis 1963/64)
