Tarantella F526WP
Blaupunkt (Ideal), Berlin, später Hildesheim
- Country
- Germany
- Manufacturer / Brand
- Blaupunkt (Ideal), Berlin, später Hildesheim
- Year
- 1952–1954
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 19250
-
- alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
- Brand: Rotstern
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Number of Transistors
- Semiconductors
- B250C85
- Main principle
- Superheterodyne (common); ZF/IF 450/10700 kHz
- Tuned circuits
- 6 AM circuit(s) 9 FM circuit(s)
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Power type and voltage
- Alternating Current supply (AC) / 110; 125; 220; 240 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 4 W (max.)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Tarantella F526WP - Blaupunkt Ideal, Berlin,
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 500 x 340 x 230 mm / 19.7 x 13.4 x 9.1 inch
- Notes
- Antennenwähler mit 5 Schaltstellungen.
- Net weight (2.2 lb = 1 kg)
- 9.7 kg / 21 lb 5.9 oz (21.366 lb)
- Price in first year of sale
- 259.00 DM
- External source of data
- Erb
- Source of data
- Kat.d.Rundf.GrossH.1953/54
- Literature/Schematics (1)
- -- Original-techn. papers.
- Literature/Schematics (2)
- -- Original prospect or advert (Point Bleu Prospekt, 1953-1954)
