• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1972–1974

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 28830

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 2

• Semiconductors
• 2SC458 2SC458 FA6017 HA1312 1N34A 1N34A 1SZ371

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220 / 4 × 1,5 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 0.7 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Twen Commander 7.614.150 - Blaupunkt Ideal, Berlin,

• Dimensions (WHD)
• 270 x 185 x 62 mm / 10.6 x 7.3 x 2.4 inch

• Notes

• Automatische oder manuelle Aussteuerung mit Instrument. Anschluss für Fernbedien-Mikrofon.

• Net weight (2.2 lb = 1 kg)
• 2.3 kg / 5 lb 1.1 oz (5.066 lb)

• External source of data
• Erb

• Source of data
• Handbuch VDRG 1972/1973

• Literature/Schematics (1)
• -- Original-techn. papers.
