Valencia 7.678.730

• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1968–1971

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 116644

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• A59-23W

• Number of Transistors
• 23

• Semiconductors

• Main principle
• Superheterodyne (common)

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Valencia 7.678.730 - Blaupunkt Ideal, Berlin,

• Shape
• Tablemodel with Push Buttons.

• Dimensions (WHD)
• 580 x 465 x 310 mm / 22.8 x 18.3 x 12.2 inch

• Notes
• VHF/UHF-Einblock-Tuner, Verbindung zwischen Steuerteil und Fernsehgerät über 10 m langes Kabel.
  Valencia T auf Grundplatte drehbar, Valencia S auf Lenkrollengestell.

• Source of data
• Handbuch VDRG 1968/1969

• Author
• Model page created by Bernd P. Kieck. See "Data change" for further contributors.
