• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1980 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 111359

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• 2SD638 2SB641 2SC1328 2SD636 2SD636 2SD636 2SD636 Tr.Gl.=Metal-rectif.

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - For headphones or amp.

• from Radiomuseum.org
• Model: Automatic Direct Drive XQ-240 7.620.510 - Blaupunkt Ideal, Berlin,

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 425 x 143.5 x 376 mm / 16.7 x 5.6 x 14.8 inch

• Notes
• ICs: 4.
  Automatic Plattenspieler.

• Mentioned in
• - - Manufacturers Literature

• Literature/Schematics (1)
• -- Original-techn. papers. (Katalog, Audio-Programm 1980/81)

• Author
• Model page created by Josef Pilz. See "Data change" for further contributors.
