Radiogramola HI-FI B-90 Ch= 8 válvulas
Bonvehi Radio; Barcelona
- Country
- Spain
- Manufacturer / Brand
- Bonvehi Radio; Barcelona
- Year
- 1955 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 273220
Foto del folleto
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 470 kHz
- Wave bands
- Broadcast and Short Wave (SW).
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 125 Volt
- Loudspeaker
- 3 Loudspeakers
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radiogramola HI-FI B-90 Ch= 8 válvulas - Bonvehi Radio; Barcelona
- Shape
- Console with Push Buttons.
- Dimensions (WHD)
- 590 x 940 x 410 mm / 23.2 x 37 x 16.1 inch
- Notes
-
Puede usar un juego de válvulas alternativo compuesto por:
ECH42, EAF42, EAF42 (EF86), 12AU7, EM34, 2x EL84 (6F6), EZ81
- Literature/Schematics (1)
- -- Schematic
- Author
- Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
