• Country
• United States of America (USA)

• Manufacturer / Brand
• Boonton Electronics Corp. (BEC); Morris Plains, NJ

• Year
• 1966 ??

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 297440

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 4

• Valves / Tubes
• 12AX7 6AU6 12AT7 6X4 0A2

• Number of Transistors

• Semiconductors
• 1N600 1N600 SG22 SG22

• Wave bands
• - without

• Power type and voltage
• Alternating Current supply (AC) / 210-250 Volt

• Material
• Metal case

• from Radiomuseum.org
• Model: 91-CA RF Voltmeter - Boonton Electronics Corp. BEC;

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 180.6 x 279.4 x 241.3 mm / 7.1 x 11 x 9.5 inch

• Notes

• RF vacuum tube voltmeter.

  Accessories:
  Probe model 91-3B
  50 Ω Adapter 91-8B

• Net weight (2.2 lb = 1 kg)
• 5.440 kg / 11 lb 15.7 oz (11.982 lb)

• Price in first year of sale
• 495.00 US$

• Mentioned in
• -- Schematic

• Author
• Model page created by Giuseppe Camarca. See "Data change" for further contributors.
