Micro System CD
Boston Acoustics; Peabody, MA
- Country
- United States of America (USA)
- Manufacturer / Brand
- Boston Acoustics; Peabody, MA
- Year
- 2004
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 298619
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Wave bands
- Broadcast, Long Wave, Short Wave plus FM or UHF.
- Details
- CD-Player, -Writer, MD, MOD (audio); Remote Control (with wire or wireless)
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- 2 Loudspeakers
- Material
- Plastics (no bakelite or catalin)
- from Radiomuseum.org
- Model: Micro System CD - Boston Acoustics; Peabody, MA
- Shape
- Tablemodel with Clock ((Alarm-) Clock Radio).
- Dimensions (WHD)
- 355 x 115 x 215 mm / 14 x 4.5 x 8.5 inch
- Notes
-
With back-up battery 9 V.
12 AM and 12 FM presets.
Available color options: black and white.Plays MP3 / WMA CDs. The model has no CD burning function.
Timer / Alarm / Sleep / function.1 x line out audio output (RCA jack); 3 audio inputs (2 x RCA + 1 x 3.5 mm jack); Headphone jack 3.5 mm ; Bass balance control;
Antenna jacks for FM and AM
Abspielen von MP3/WMA-CDs.Das Modell hat keine CD-Brennfunktion !
Timer-/Alarm-/Schlummer-/Sleep-Funktion.1 x line out Audio-Ausgang ( Cinch-Buchse) ; 3 Audio-Eingänge (2 x Cinch + 1 x 3,5 mm Klinke);Kopfhöreranschluß 3,5 mm Klinke.;Baßabgleich-Regler;
Antennenbuchsen je für UKW- und AM- Empfang
- Net weight (2.2 lb = 1 kg)
- 4.225 kg / 9 lb 4.9 oz (9.306 lb)
- Source of data
- - - Manufacturers Literature
- Author
- Model page created by a member from D. See "Data change" for further contributors.
