Aeroplane Radio Antenna Reel DR-2
Brach Mfg. Co.,L.S.; Newark (NJ)
- Country
- United States of America (USA)
- Manufacturer / Brand
- Brach Mfg. Co.,L.S.; Newark (NJ)
- Year
- 1918
- Category
- Military Equipment (not Re, Tr or RXT)
- Radiomuseum.org ID
- 355144
- Main principle
- something special ? Please give information (notes)
- Power type and voltage
- No Power needed
- Loudspeaker
- - - No sound reproduction output.
- Material
- Metal case
- from Radiomuseum.org
- Model: Aeroplane Radio Antenna Reel DR-2 - Brach Mfg. Co.,L.S.; Newark NJ
- Dimensions (WHD)
- 7 x 1.5 x 1.5 inch / 178 x 38 x 38 mm
- Notes
-
Made for the Signal Corps U.S. Army. Aeroplane Radio Antenna Reel Type DR-2 order No. 42291. Date April 4, 1918. Made by L.S. Brach Supply Company, Newark, New Jersey.
This antenna reel was used in the De Havilland DH-4 and the Curtiss JN-4 Aircraft. It was used with the BC-15A and SCR-65A radio Sets.
- Mentioned in
- -- Original-techn. papers. (Airplane Radio Telegraph Transmitting Sets, Radio Pamphlet No. 5, Signal Corps U.S. Army)
- Author
- Model page created by Robert Benson. See "Data change" for further contributors.
