• Country
• Germany

• Manufacturer / Brand
• Brandt (Roland Brandt); Berlin

• Year
• 1936/1937

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 1034

• • alternative name: Motorfahrzeug-Fabrik

• Number of Tubes
• 3

• Valves / Tubes
• KC1_4pin KC1_4pin KL1_5pin

• Main principle
• TRF with regeneration; 2 AF stage(s)

• Tuned circuits
• 1 AM circuit(s)

• Wave bands
• Broadcast (MW) and Long Wave.

• Power type and voltage
• Storage and/or dry batteries / 100 / 2 Volt

• Loudspeaker
• Magnetic loudspeaker (reed) of high quality (free mooving - only possible past 1931).

• from Radiomuseum.org
• Model: Columbus K [Koffer] - Brandt Roland Brandt; Berlin

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 370 x 280 x 180 mm / 14.6 x 11 x 7.1 inch

• Notes
• Kunstleder, Rolljalousie

• Net weight (2.2 lb = 1 kg)
• 4.2 kg / 9 lb 4 oz (9.251 lb)

• Price in first year of sale
• 118.00 RM

• Source of data
• HandB.d.d.Rundfunk-Handels 1936/37 / Radiokatalog Band 1, Ernst Erb

• Circuit diagram reference
• Röhren in FS-Bestückungstabellen
