• Country
• Germany

• Manufacturer / Brand
• Blaupunkt (Ideal), Berlin, später Hildesheim

• Year
• 1962/1963

• Category
• Television Receiver (TV) or Monitor

• Radiomuseum.org ID
• 105943

• • alternative name: Ideal-Radiotelephon- und App-fabr. || Ideal-Werke AG; Berlin (ab 1934)
  • Brand: Rotstern

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 18

• Valves / Tubes
• PC88 PC86 PCC88 PCF82 PC92 EF80 PCL86 EF80 EF80 EF184 PCL84 ECH84 PCL85 ECH84 PL36 PY88 DY86 AW59-90

• Number of Transistors
• 1

• Semiconductors
• AF115

• Main principle
• Superheterodyne (common); ZF/IF 38900 kHz

• Wave bands
• Wave Bands given in the notes.

• Details
• Remote Control (with wire or wireless)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• 2 Loudspeakers

• Material
• Wooden case

• from Radiomuseum.org
• Model: Palma de luxe 72410 [18 Röhren] - Blaupunkt Ideal, Berlin,

• Shape
• Tablemodel, low profile (big size).

• Dimensions (WHD)
• 690 x 485 x 335 mm / 27.2 x 19.1 x 13.2 inch

• Notes
• VHF/UHF.

• Net weight (2.2 lb = 1 kg)
• 33 kg / 72 lb 11 oz (72.687 lb)

• Price in first year of sale
• 1,198.00 DM

• Source of data
• Handbuch VDRG 1962/1963

• Literature/Schematics (1)
• -- Original-techn. papers.

• Author
• Model page created by Walter Wiesmüller † May 2012. See "Data change" for further contributors.
