Empire 330A
Breville; Sydney
- Country
- Australia
- Manufacturer / Brand
- Breville; Sydney
- Year
- 1941 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 356388
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 446 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 240 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
- Material
- Wooden case
- from Radiomuseum.org
- Model: Empire 330A - Breville; Sydney
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 478 x 327 x 270 mm / 18.8 x 12.9 x 10.6 inch
- Notes
-
This is a variant of the original 330 using different valves and a different audio circuit.
- Author
- Model page created by Stuart Irwin. See "Data change" for further contributors.
