• Country
• United States of America (USA)

• Manufacturer / Brand
• Broksonic; New York (NY)

• Year
• 1975 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 229010

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 14

• Semiconductors
• 2SC1359 2SC829 2SC829 2SC829 2SC829 2SA52 2SB173 2SB175 2SC828 2SB54 2SB54 2SB54 2SB324 2SB324

• Main principle
• Superheterodyne (common); ZF/IF 455/10700 kHz; 3 AF stage(s)

• Wave bands
• Broadcast (BC) and FM or UHF.

• Power type and voltage
• Line / Batteries (any type) / 120; 220 / C 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: AM-FM Cassette Recorder C-225 - Broksonic; New York NY

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 285 x 200 x 85 mm / 11.2 x 7.9 x 3.3 inch

• Notes

• Wave ranges:

  •  MW - 535 to 1605 kHz
  •  FM - 88 to 108 MHz.

  Made in Japan

• Net weight (2.2 lb = 1 kg)
• 6.9 lb (6 lb 14.4 oz) / 3.133 kg

• Author
• Model page created by João Luis Mendes Colaço. See "Data change" for further contributors.

• Other Models

• Here you find 5 models, 4 with images and 0 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
  All listed radios etc. from Broksonic; New York (NY)
