B&K Television Analyst 1076

• Country
• United States of America (USA)

• Manufacturer / Brand
• B&K (Precision), Dynascan Corp., Cobra Electronics; Chicago, IL and Yorba Linda, CA

• Year
• 1960

• Category
• Service- or Lab Equipment

• Radiomuseum.org ID
• 184488

• • alternative name: B&K Manufacturing Company

• Picture
• Schematics

Previous Next

Previous Next

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 16

• Valves / Tubes
• 931A 12AT7 12AU7 12AT7 6CB6 6AN8 12AX7 6DE7 6CG7 6DQ6 6DQ6 6AX4 1X2 12AU7 6CA4 5BKPV-1

• Wave bands
• VHF incl. FM and/or UHF (see notes for details)

• Power type and voltage
• Alternating Current supply (AC) / 115/230 Volt

• Loudspeaker
• - - No sound reproduction output.

• Material
• Metal case

• from Radiomuseum.org
• Model: B&K Television Analyst 1076 - B&K Precision, Dynascan Corp.,

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 430 x 220 x 220 mm / 16.9 x 8.7 x 8.7 inch

• Notes
• B+K Fernseh-Analysator 1076;
  Signalgenerator für Reparaturen an schwarzweiß und Farb - TV.
  Direkte Punkt-zu-Punkt-Signalzuführung möglich.
  Hersteller: Dynascan Corporation; Chicago (IL).
  Nicht zu verwechseln mit B&K (Bruel & Kjaer), Dänemark. VHF Canal 3 y 4, Normas "N"

• Net weight (2.2 lb = 1 kg)
• 12 kg / 26 lb 6.9 oz (26.432 lb)

• Price in first year of sale
• 300.00 $

• Author
• Model page created by Museum Roggenhofer. See "Data change" for further contributors.
