Precision Sound Level Meter 2203 Tube

Brüel & Kjær; Nærum

Data
Forum
Pictures
Collections

  • Year
  • 1960
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 191626

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 1
  • Number of Transistors
  • 18
  • Main principle
  • Audio-Amplification
  • Wave bands
  • - without
  • Power type and voltage
  • Dry Batteries / 3 x 1,5 Volt
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Precision Sound Level Meter 2203 [Tube] - Brüel & Kjær; Nærum
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 120 x 310 x 90 mm / 4.7 x 12.2 x 3.5 inch
  • Notes
  • The Brüel & Kjær model 2203 was the world’s first precision hand-held and transistorised sound level meter. Type 2203 is a highly accurate instrument for sound level measurements. To make it convenient for field and outdoor use, as well as for laboratory measurements, it is designed as a portable battery-driven and rugged unit equipped with high quality components.
    Used in conjunction with a suitable filter set (e.g. the Octave Filter 1613), the instrument can be converted into a handy and easily operated frequency analyzer.
    Measuring range with 1" B&K condenser microphone 4131:
    Sound Pressure Level 31...134dB
    Sound level (weighted) 22...134 dB
    Octave Sound Pressure Level 20...134 dB.
    Switchable weighting filters for A, B and C curves or linear measurements.
  • Net weight (2.2 lb = 1 kg)
  • 2.7 kg / 5 lb 15.2 oz (5.947 lb)
  • Source of data
  • - - Manufacturers Literature
  • Mentioned in
  • -- Original-techn. papers.
  • Author
  • Model page created by Bernhard Nagel. See "Data change" for further contributors.
