Terz/Oktav Analysator 2112 late
Brüel & Kjær; Nærum
- Country
- Denmark
- Manufacturer / Brand
- Brüel & Kjær; Nærum
- Year
- 1967 ?
- Category
- Service- or Lab Equipment
- Radiomuseum.org ID
- 125946
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Number of Transistors
- 1
- Semiconductors
- Main principle
- Audio-Amplification
- Wave bands
- - without
- Power type and voltage
- 100; 115; 127; 150; 220; 240 Volt
- from Radiomuseum.org
- Model: Terz/Oktav Analysator 2112 [late] - Brüel & Kjær; Nærum
- Shape
- Tablemodel, high profile (upright - NOT Cathedral nor decorative).
- Dimensions (WHD)
- 380 x 480 x 200 mm / 15 x 18.9 x 7.9 inch
- Net weight (2.2 lb = 1 kg)
- 20 kg / 44 lb 0.8 oz (44.053 lb)
- Source of data
- - - Data from my own collection
- Author
- Model page created by Vaclav Skricka. See "Data change" for further contributors.
