• Country
• United States of America (USA)

• Manufacturer / Brand
• Brunswick-Balke-Collender Co.

• Year
• 1931/1932

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 18465

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• 51 24 24 51 24 47 80

• Main principle
• Superhet with RF-stage; ZF/IF 175 kHz

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Alternating Current supply (AC) / 105-110; 115-130 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 11 [w/o AVC] - Brunswick-Balke-Collender Co.

• Shape
• Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.

• Dimensions (WHD)
• 17.5 x 21 x 10 inch / 445 x 533 x 254 mm

• Notes

• There is also a model 11 with an AVC chassis D.

  Tone control.

• Price in first year of sale
• 80.00 $

• External source of data
• E. Erb 3-907007-36-0

• Source of data
• Collector's Guide to Antique Radios (7th Edition)

• Circuit diagram reference
• Die «Thali Schemasammlung» führt das Modell.

• Mentioned in
• Radio Collector`s Guide 1921-1932

• Literature/Schematics (1)
• Rider's Perpetual, Volume 2 = 1932 and before (Radio College of Canada, Individual Circuit Service, 1927-1953)

• Literature/Schematics (2)
• Cathedral & Tombstone Radios (page 67.)

• Literature/Schematics (3)
• -- Schematic (La Riparazione degli Apparecchi Radio Delforno-Colciago - Lavagnolo - Italy - 1941)
