• Country
• Great Britain (UK)

• Manufacturer / Brand
• BSR (Brand), Birmingham Sound Reproducers Ltd.; Staffordshire

• Year
• 1960 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 152557

• • Brand: Birmingham Sound Reproducers

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Details
• Changer (Record changer)

• Power type and voltage
• Alternating Current supply (AC) / 100-125; 200-250 Volt

• Loudspeaker
• - For headphones or amp.

• Material
• Metal case

• from Radiomuseum.org
• Model: Monarch UA14 - BSR Brand, Birmingham Sound

• Shape
• Chassis only or for «building in»

• Dimensions (WHD)
• 335 x 115 x 285 mm / 13.2 x 4.5 x 11.2 inch

• Notes

• Height is measured above mounting plate. Fitted with a TC8M mono crystal cartridge with a TC8R LP/78 turnover stylus.

• Literature/Schematics (1)
• Photofact Folder, Howard W. SAMS (Set 465, Folder 6, Jan. 1960.)

• Literature/Schematics (2)
• -- Original-techn. papers. (Philco Phonograph Service Manual PR-3704)

• Author
• Model page created by Georges Van Campenhout † 28.4.22. See "Data change" for further contributors.
