- Country
- Great Britain (UK)
- Manufacturer / Brand
- Bush Radio Ltd.; london
- Year
- 1938
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 108956
Ebay Auction UK
- Number of Tubes
- 8
- Main principle
- Superheterodyne (common); ZF/IF 465 kHz; 2 AF stage(s)
- Wave bands
- Broadcast, Long Wave and Short Wave.
- Power type and voltage
- Alternating Current supply (AC) / 210; 230; 250 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 10 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: PB55 - Bush Radio Ltd.; london
- Shape
- Tablemodel with Push Buttons.
- Dimensions (WHD)
- 21 x 17.25 x 12.5 inch / 533 x 438 x 318 mm
- Notes
- Manual tuning covering three wavebands. Eight push buttons for preset radio stations on MW and LW. Similar chassis in the SUG55 console model.
- Mentioned in
- -- Original-techn. papers.
- Author
- Model page created by Roy Johnson. See "Data change" for further contributors.
