• Country
• Great Britain (UK)

• Manufacturer / Brand
• Bush Radio; London

• Year
• 1951

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 103241

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 7

• Valves / Tubes
• ECH42 EF41 EBC41 EBC41 EL41 EL41 EZ40

• Main principle
• Superheterodyne (common); ZF/IF 465 kHz

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Power type and voltage
• Alternating Current supply (AC) / 100-127; 200-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm

• Power out
• 8 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: SUG26 - Bush Radio; London

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 20 x 32.5 x 11 inch / 508 x 826 x 279 mm

• Net weight (2.2 lb = 1 kg)
• 18.1 kg / 39 lb 13.9 oz (39.868 lb)

• Mentioned in
• -- Original-techn. papers.

• Literature/Schematics (1)
• Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1053)

• Author
• Model page created by Peter Hoddow. See "Data change" for further contributors.
