• Country
• Great Britain (UK)

• Manufacturer / Brand
• Bush Radio Ltd.; london

• Year
• 1958

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 79421

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• UCC85 UF89 UF89 UF89 UABC80 UL84

• Number of Transistors

• Semiconductors
• Metal-rectifier

• Main principle
• Superhet with RF-stage; ZF/IF 10700 kHz

• Tuned circuits
• 11 FM circuit(s)

• Wave bands
• FM Broadcast Band Only

• Power type and voltage
• AC/DC-set / 200-250 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Power out
• 2 W (unknown quality)

• Material
• Bakelite case

• from Radiomuseum.org
• Model: VHF90A - Bush Radio Ltd.; london

• Shape
• Tablemodel without push buttons, Mantel/Midget/Compact up to 14

• Dimensions (WHD)
• 13.7 x 9.25 x 6.6 inch / 348 x 235 x 168 mm

• Notes

• An AC/DC mains FM table in a compact bakelite cabinet covering VHF 87.5-100 MHz. Elliptical loudspeaker 6 x 4 inch. An ordinary scale lamp (6.0 V / 0.5 A, M.E.S. base) works as a fuse. The scale lamp is a large clear bulb with an S.B.C. base (230V, 15W). Socket for an external aerial. Released May 1958, price £12 17s 0d plus purchase tax.

• Net weight (2.2 lb = 1 kg)
• 3.9 kg / 8 lb 9.4 oz (8.59 lb)

• Price in first year of sale
• 18.00 GBP

• Source of data
• Radio! Radio!

• Literature/Schematics (1)
• -- Schematic

• Literature/Schematics (2)
• Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (1362 dated 26 July 1958)

• Literature/Schematics (3)
• Radio And Television Servicing books (R&TVS)

• Author
• Model page created by Konrad Birkner † 12.08.2014. See "Data change" for further contributors.
