Bonus EBS 143
BUSH Limited India; Bombay
- Country
- India
- Manufacturer / Brand
- BUSH Limited India; Bombay
- Year
- 1965 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 332764
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast plus 2 Short Wave bands.
- Power type and voltage
- AC/DC-set / 40-100 Hz or DC: 220-250 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Material
- Bakelite case
- from Radiomuseum.org
- Model: Bonus EBS 143 - BUSH Limited India; Bombay
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 13 x 9 x 7 inch / 330 x 229 x 178 mm
- Notes
-
"Manufactured by a company in association with the Rank Organisation."
- Net weight (2.2 lb = 1 kg)
- 4.5 kg / 9 lb 14.6 oz (9.912 lb)
- Author
- Model page created by Uday Kalburgi. See "Data change" for further contributors.
