• Country
• Canada

• Manufacturer / Brand
• Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC

• Year
• 1938 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 298757

• • alternative name: CMC Canada || Marconi, Canada

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• 6A8 6K7 6Q7 6F6 5Y4G

• Main principle
• Superheterodyne (common); ZF/IF 462.5 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and Short Wave (SW).

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm

• Power out
• 1 W (2.3 W max.)

• from Radiomuseum.org
• Model: 112 - Canadian Marconi Co. Ltd. CMC,

• Notes

• The Canadian Marconi model 112 is a 5-tube radio for standard broadcast and 31m (9.4-9.7 MHz) shortwave reception.

• Literature/Schematics (1)
• Marconi Service Manual (Volume 1) (Page 213-216)

• Author
• Model page created by Tom Seeger. See "Data change" for further contributors.
