• Year
  • 1939 ?
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 298809
    • alternative name: CMC Canada || Marconi, Canada

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 5
  • Main principle
  • Superheterodyne (common); ZF/IF 462.5 kHz; 3 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast plus 2 Short Wave bands.
  • Power type and voltage
  • Storage and/or dry batteries / 1.5 & 4.5 & 6 & 2 x 45 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
  • Power out
  • 0.35 W (0.75 W max.)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: 129A - Canadian Marconi Co. Ltd. CMC,
  • Shape
  • Console with Push Buttons.
  • Notes
  • The Canadian Marconi model 129A is a 5-tube battery operated radio for standard broadcast and shortwave reception. Covers 540-1725 kHz and 5.5-13 MHz and 13-22 MHz.

  • Author
  • Model page created by Tom Seeger. See "Data change" for further contributors.
