• Country
• Canada

• Manufacturer / Brand
• Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC

• Year
• 1940 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 197637

• • alternative name: CMC Canada || Marconi, Canada

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 6

• Valves / Tubes
• 6K8 6K7 6Q7 6F6G 6U5 5Y4G

• Main principle
• Superheterodyne (common); ZF/IF 462.5 kHz; 2 AF stage(s)

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast plus more than 2 Short Wave bands.

• Power type and voltage
• Alternating Current supply (AC) / 115 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm

• Power out
• 1.7 W (4 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 168 - Canadian Marconi Co. Ltd. CMC,

• Shape
• Console with Push Buttons.

• Notes

• 5 wave bands: BC, SW 49m, SW 31m, SW 25m and SW 19m.

• Source of data
• Pre-War Consoles

• Literature/Schematics (1)
• Marconi Service Manual (Volume 1) (P. 381-384)

• Author
• Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
