1A-18805-A

Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC

Data

Forum

Pictures

Collections

Country
Canada

Manufacturer / Brand
Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC

Year
1951 ?

Category
Car Radio, perhaps also + sound player/recorder

Radiomuseum.org ID
311836

- alternative name: CMC Canada || Marconi, Canada

Schematics

1A-18805-A ; Canadian Marconi Co. (ID = 2407376) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407377) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407378) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407379) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407380) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407381) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407382) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407383) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407384) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407386) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2407387) Car Radio — Canadian Marconi Co. 1A-18805-A (3)

1A-18805-A ; Canadian Marconi Co. (ID = 2443180) Car Radio — Canadian Marconi Co. 1A-18805-A (1)

1A-18805-A ; Canadian Marconi Co. (ID = 2443181) Car Radio — Canadian Marconi Co. 1A-18805-A (1)

1A-18805-A ; Canadian Marconi Co. (ID = 2806818) Car Radio — Canadian Marconi Co. 1A-18805-A (2)

1A-18805-A ; Canadian Marconi Co. (ID = 2806819) Car Radio — Canadian Marconi Co. 1A-18805-A (2)
Picture from Stan Marlin.

1A-18805-A ; Canadian Marconi Co. (ID = 2806820) Car Radio — Canadian Marconi Co. 1A-18805-A (2)
Picture from Stan Marlin.

1A-18805-A ; Canadian Marconi Co. (ID = 2806822) Car Radio — Canadian Marconi Co. 1A-18805-A (2)
Picture from Stan Marlin.

1A-18805-A ; Canadian Marconi Co. (ID = 2806824) Car Radio — Canadian Marconi Co. 1A-18805-A (2)
Picture from Stan Marlin.

1A-18805-A ; Canadian Marconi Co. (ID = 2806825) Car Radio — Canadian Marconi Co. 1A-18805-A (2)
Picture from Stan Marlin.

Click on the schematic thumbnail to request the schematic as a free document.

Technical Specifications

Number of Tubes
0

Valves / Tubes
6SK7 6SA7 6SK7 6SQ7 6V6GT 6X5GT

Main principle
Superheterodyne (common); ZF/IF 265 kHz

Tuned circuits
7 AM circuit(s)

Wave bands
Broadcast only (MW).

Power type and voltage
Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt

Loudspeaker
- This model requires external speaker(s).

Material
Metal case

from Radiomuseum.org
Model: 1A-18805-A - Canadian Marconi Co. Ltd. CMC,

Shape
Chassis only or for «building in»

Notes
For use in 1951 Ford and Meteor cars.

Mentioned in
- - Manufacturers Literature

Author
Model page created by Rick Williams. See "Data change" for further contributors.
