- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1941/1942
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 215674
-
- alternative name: CMC Canada || Marconi, Canada
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 462.5 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
- Power out
- 2 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 203 - Canadian Marconi Co. Ltd. CMC,
- Shape
- Console with Push Buttons.
- Notes
- The schematic is identical to model 202. We copied the model 203 only from that schematic - for a cabinet version 203 that has a separate 12 inch speaker. Wave switch can also select push buttons for 6 broadcast presets. Six-button, permeability tuned type automatic station selector, covering the frequencies: 540 - 900 kc (2 x), 600 - 950 kc, 700 - 1200 kc (2 x) and 950 - 1550 kc. Frequency coverage is broadcast 538 - 1728 kc, short-wave band 5.6 - 18.8 mc.
- Author
- Model page created by Ernst Erb. See "Data change" for further contributors.
- Other Models
-
Here you find 462 models, 325 with images and 378 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
