- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1946 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 214636
-
- alternative name: CMC Canada || Marconi, Canada
Picture from Marconi Service Manual
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 462.5 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 6 inch = 15.2 cm
- Power out
- 1.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 219 - Canadian Marconi Co. Ltd. CMC,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 19.5 x 11.12 x 9.25 inch / 495 x 282 x 235 mm
- Notes
- The Marconi Model 219 is an AC operated 6 Tube BC/SW Receiver. BC Band Tuning Range: 540 to 1720kHz. SW Band Tuning Range: 5.8 to 18.0MHz. Marconi Model 220 uses the same chassis and schematic. Operates with either 25 or 60Hz AC power.
- Literature/Schematics (1)
- Marconi Service Manual Volume No. 2 (Volume 2, Page 45)
- Author
- Model page created by John Kusching. See "Data change" for further contributors.
