- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1947/1948
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 150996
-
- alternative name: CMC Canada || Marconi, Canada
From a Canadian Kijiji advertisement.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Alternating Current supply (AC) / 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Power out
- 4 W (unknown quality)
- Material
- Bakelite case
- from Radiomuseum.org
- Model: 281 - Canadian Marconi Co. Ltd. CMC,
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 14.75 x 9.125 x 7.375 inch / 375 x 232 x 187 mm
- Notes
- The Marconi Model 281 is an AC operated 6 Tube BC Receiver. BC Band Tuning Range: 540 to 1720kHz. Has built-in loop antenna. Two output tubes (6AQ5) operate in parallel. Operates with either 25 or 60Hz AC power. Marconi Table Model 279 uses the same chassis and schematic.
- Circuit diagram reference
- Radio College of Canada
- Mentioned in
- Suppl. 23 page 48
- Literature/Schematics (1)
- Marconi Service Manual Volume No. 2 (Volume 2, Page 267)
- Author
- Model page created by Ashis Mukerjea. See "Data change" for further contributors.
