- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1935/1936
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 197638
-
- alternative name: CMC Canada || Marconi, Canada
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 8
- Main principle
- Superhet with RF-stage; ZF/IF 462.5 kHz
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 115 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 3.9 W (5.5 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: 75-AC - Canadian Marconi Co. Ltd. CMC,
- Shape
- Console, Lowboy (legs < 50 %).
- Notes
-
BC (529-1725 kHz) and SW (5650-18000 kHz) bands. Magic eye tuning indicator. Two type 6F6 tubes in parallel.
- Price in first year of sale
- 154.50 $
- Source of data
- Pre-War Consoles
- Literature/Schematics (1)
- Radio College of Canada (RCC) (Marconi data sheet 40 & 41)
- Literature/Schematics (2)
- Marconi Service Manual (Volume 1) (Pages 115 to 118)
- Literature/Schematics (3)
- Marconi Folder for 1936.
- Author
- Model page created by Hans-Joachim Korn † 16.11.15. See "Data change" for further contributors.
