- Country
- Canada
- Manufacturer / Brand
- Canadian Marconi Co. Ltd. (CMC, Esterline), Marconi's Wireless; Montreal, QC
- Year
- 1952 ?
- Category
- Car Radio, perhaps also + sound player/recorder
- Radiomuseum.org ID
- 305653
-
- alternative name: CMC Canada || Marconi, Canada
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 265 kHz; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 6 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
- Power out
- 2.5 W (unknown quality)
- Material
- Metal case
- from Radiomuseum.org
- Model: CFAB-18805-A - Canadian Marconi Co. Ltd. CMC,
- Shape
- Chassis only or for «building in»
- Notes
-
The Marconi model CFAB-18805-A is a 6-tube car radio with push buttons for 5 preset frequencies. Has vibrator type B+ supply. Supplied with 6 x 9 inch oval speaker. Used in several 1952 Ford and Mercury model cars.
- Literature/Schematics (1)
- Radio College of Canada (RCC) (1953 Supplement 29)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
