- Country
- Canada
- Manufacturer / Brand
- Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
- Year
- 1948 ?
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 296580
From CGE service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 21
- Valves / Tubes
- 6AU6 6AU6 6AG5 12AT7 6AU6 6AU6 6AU6 6AL5 12AU7 10BP4 12SN7 19BG6 1B3GT 25W4 6AU6 6AL5 6SQ7 25L6GT 6SL7GT 12SN7 6AL5
- Main principle
- Superhet with RF-stage; ZF/IF 4500/26300 kHz
- Wave bands
- Wave Bands given in the notes.
- Power type and voltage
- Alternating Current supply (AC) / 25 to 60 Hz,115 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 inch = 25.4 cm
- Power out
- 1 W (2 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: C2509 - Canadian General Electric
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 20 x 35.5 x 21.1 inch / 508 x 902 x 536 mm
- Notes
-
The Canadian General Electric model C2509 is an 11 inch black and white television receiver with North American standard VHF tuner for channels 2-13.
- Literature/Schematics (1)
- General Electric Radio and Television Service Manual 1945-1949 (Page 413 to 434)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
- Other Models
-
Here you find 505 models, 373 with images and 428 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
All listed radios etc. from Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
