- Country
- Canada
- Manufacturer / Brand
- Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
- Year
- 1948 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 287982
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; ZF/IF 460 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 105-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6 inch = 15.2 cm
- Power out
- 3 W (6 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: C-3266 - Canadian General Electric
- Shape
- Tablemodel, with any shape - general.
- Dimensions (WHD)
- 17 x 11.5 x 9 inch / 432 x 292 x 229 mm
- Notes
-
The Canadian General Electric model C-3266 is a 6 tube AC only table radio covering standard broadcast and shortwave. Shortwave tuning range is 5.5 to 18 MHz.
The C-3266 uses a built in loop antenna for standard broadcast and shortwave reception.
- Literature/Schematics (1)
- General Electric Radio and Television Service Manual 1945-1949
