• Country
• Canada

• Manufacturer / Brand
• Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON

• Year
• 1947 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 295467

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 11

• Valves / Tubes
• 6AG5 6AK5 6AK5 6SG7 6AL7GT 6SV7 6SH7 6AQ7GT 6SC7 6V6GT 5Y4G

• Main principle
• Superhet with RF-stage; ZF/IF 460/10700 kHz

• Tuned circuits
• 8 AM circuit(s)     7 FM circuit(s)

• Wave bands
• Broadcast, 2 Short Wave plus FM or UHF.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 105 to 125 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm

• Power out
• 4 W (5.5 W max.)

• Material
• Wooden case

• from Radiomuseum.org
• Model: C-417A - Canadian General Electric

• Shape
• Console with any shape - in general

• Dimensions (WHD)
• 35 x 35 x 17.5 inch / 889 x 889 x 445 mm

• Notes

• The Canadian General Electric model C-417A is an 11-tube, 5 band AM / FM console radio with tuning eye tube and automatic record changer. Cabinet has a walnut finish. For 25 or 60 Hz depending on nameplate rating.
  Band coverage is as follows;

  Standard Broadcast: 540 to 1600 kHz
  Shortwave 1: 9.4 to 9.9 MHz
  Shortwave 2: 11.6 to 12.1 MHz
  FM1: 42 to 50 MHz
  FM2: 88 to 108 MHz



• Literature/Schematics (1)
• General Electric Radio and Television Service Manual 1945-1949 (Pages 185 to 192)
