- Country
- Canada
- Manufacturer / Brand
- Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
- Year
- 1947/1948
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 94215
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 10
- Main principle
- Superhet with RF-stage; ZF/IF 460/10700 kHz
- Wave bands
- Broadcast, 2 Short Wave plus FM or UHF.
- Details
- Record Player (perh.Changer)
- Power type and voltage
- Alternating Current supply (AC) / 25 or 60 Hz, 100-125 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 inch = 30.5 cm
- Power out
- 4 W (5.5 W max.)
- Material
- Wooden case
- from Radiomuseum.org
- Model: C-417 - Canadian General Electric
- Shape
- Console, Lowboy (legs < 50 %).
- Dimensions (WHD)
- 35 x 35 x 17.5 inch / 889 x 889 x 445 mm
- Notes
-
The Canadian General Electric model C-417 is a 10 Tube, 5 Band, AM, FM receiver with built in automatic phonograph record changer. The phonograph uses a magnetic type pickup.
Band coverage is as follows:
Broadcast: 540-1600 kHz.
Shortwave 1: 9400-9900 kHz.
Shortwave 2: 11600-12100 kHz.
FM1: 42-50 MHz.
FM2: 88-108 MHz.
The line frequency is 25 or 60 Hz dependant on nameplate.
- Literature/Schematics (1)
- General Electric Radio and Television Service Manual 1945-1949 (Radio College of Canada, Individual Circuit Service, 1927-1953)
- Author
- Model page created by Vitor Oliveira. See "Data change" for further contributors.
