- Country
- Canada
- Manufacturer / Brand
- Canadian General Electric (Canada) (C.G.E. or CGE); Toronto, ON
- Year
- 1945 ?
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 295468
From service manual.
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 5
- Main principle
- Superheterodyne (common); ZF/IF 460 kHz; 2 AF stage(s)
- Tuned circuits
- 6 AM circuit(s)
- Wave bands
- Broadcast only (MW).
- Power type and voltage
- AC/DC-set / 105 to 117 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
- Power out
- 1.5 W (unknown quality)
- Material
- Wooden case
- from Radiomuseum.org
- Model: CL-541A - Canadian General Electric
- Shape
- Tablemodel without push buttons, Mantel/Midget/Compact up to 14
- Dimensions (WHD)
- 10.4 x 7.3 x 6.7 inch / 264 x 185 x 170 mm
- Notes
-
The Canadian General Electric model CL-541A is a 5-tube single band table radio. Covers standard broadcast with an external wire antenna. With walnut finished wood cabinet.
- Literature/Schematics (1)
- General Electric Radio and Television Service Manual 1945-1949 (Page 236 to 238)
- Author
- Model page created by Tom Seeger. See "Data change" for further contributors.
